Ultra precision fully open strong magnetic field low-temperature optical research platform - OptiCool
OptiCool is an ultra precision fully open strong magnetic field low-temperature optical research platform launched, with innovative and unique design solutions to ensure that samples can be in critical positions in the optical path. The system has a 3.8-inch ultra large sample cavity and a double cone split magnet, which can provide you with a magnetic field of up to ± 7T in a super large space. Up to 7 side windows and 1 large top window facilitate the introduction of light from various directions into the sample cavity. The highly integrated design allows your sample to have a low-temperature magnetic field while freeing it from the various constraints of large low-temperature systems.
OptiCool is a fully dry system that only requires a small amount of helium for startup and operation. Fully automatic software control to achieve one click temperature and field changes; The large sample space with a diameter of 89mm and a height of 84mm, as well as the top window with a 90 ° optical path angle, make measurement more convenient; Temperature control technology makes temperature control more intelligent; The new magnet combines a super uniform region with a super large numerical aperture. OptiCool makes low-temperature optical experiments infinitely possible.
OptiCool technology features:
·Full dry system: completely liquid helium free system, pulse tube refrigerator.
·8 optical windows:
7 side windows (NA>0.11)
1 top window (NA>0.7)
·Ultra large magnetic field: ± 7T
·Ultra low vibration:<10nm horizontal peak to peak
<4nm vertical peak to peak
·Extra large space: Φ 89mm x 84mm
·Precision temperature control: 1.7K~350K full temperature zone precision temperature control
·New type of magnet: Double cone split magnet, which meets the requirements of ultra large magnetic field uniformity zone and large numerical aperture.
The OptiCool sample compartment provides users with a workbench for custom experimental setup. When you are ready to start the experiment, the sample compartment can be conveniently placed in the pre wired temperature control sample stage. After the measurement is completed, you can easily replace it with the prepared sample compartment for the next sample measurement. OptiCool comes standard with 16 lead wires and has already been introduced to the sample chamber through heat sink on the interface panel. An additional 80 lead wires can be added.
