1、 The main purpose and characteristics of the instrument:
The XDS-900 series inverted microscope combines an excellent infinite distance microscopic optical system with modern high-quality microscopic observation methods, which can easily achieve bright field of view, phase contrast and other observations, clear and bright microscopic images, and simple and stable operations. Specially designed for the cultivation and observation of cellular tissues, with high contrast and resolution, highlighting cell contours and internal structures; And it can achieve bright field, fluorescence, phase contrast observation, etc., to meet the needs of daily laboratory work and basic research.
▲. Adopting an infinitely far positive image microscopy optical system;
▲. 360 ° rotating binocular observation tube
A rotatable binocular observation tube designed in accordance with ergonomics, with a pupil distance adjustment range of 50-75mm and a 360 ° rotation function. When the standard pupil distance is 65mm, the eye point can be raised to 34mm according to demand without relying on an eye point elevator, which is convenient and fast.
▲. Stable structural design
The XDS-900C rack is made of high rigidity aluminum alloy material by high-pressure casting, effectively ensuring the stability of image quality. The surface adopts powder spraying technology, which is anti-corrosion and wear-resistant. All its accessories have also undergone surface treatment, ensuring long-lasting performance even in harsh environments.
▲. Multiple cell culture methods can be achieved
We have reserved more expansion space for users to install various accessories, such as culture dishes, culture bottles, porous plates, etc., which can be configured according to user needs. The platform can also be equipped with mobile rulers and other accessories to fix the sample. The sample position can be adjusted through the XY coaxial mobile handle, which is convenient and fast.
▲. Safe and environmentally friendly LED lighting
Using warm colored 5W high-power LED lighting, users can easily obtain comfortable and natural images under the mirror. Its brightness is stable, not easy to generate heat, and has the characteristics of energy conservation and long-term effectiveness.
▲. Smartphone photo attachment
When the image observed by both eyes needs to be recorded in a timely manner, simply fix the phone to the eyepiece shooting device, turn on the photography function, and you can take photos without worrying about difficulties in manual focusing or image shake.
▲ New intelligent ECO system
With the design concept of environmental protection and economy, a new ECO infrared sensing system has been added. When the user leaves for a certain period of time or returns again, the system will automatically turn off the power or turn it back on, saving energy consumption.
▲ Convenient and efficient marking objective
When using a culture vessel for live cell observation, using a labeling lens can label the observed sample, making it convenient to repeatedly observe the current area and also facilitating the extraction of target cells.
